Product Detail

Model No.: TXG114.3-8.56-TXG406.4-16.6...

Production Capacity: 500 sets

Delivery Date: 40days

Means of Transport: Ocean,Land,Air

Packing: seaworthy pcaking

Brand Name: shuangjia

Washover pipe is a special toll to release the stuck section of drillstring in the well bore.

Washover pipe is a special toll to release the stuck section of drillstring in the well bore. We offer a complete ranger of washover pipe in the industry. Our unique FJWP thread is two-step double shoulder thread which assure quick make up and high torsion strength.
Drive sub: drive sub provide the crossover connection between fishing string and the washover pipe. each is machined from high-grade alloy steel and heat treated to provide maximum strength and durability.

Lifting plug: lifting plug is designed to provide an economical method of handing washover strings. It is available in all thread types and size, has sufficient shoulder diameter to support handing the washover string.

Washover safety joint: washover safety joint is manufactured to provide safe and easy release and make-up whenever disengagement from the washover string becomes necessary. This dependable, field-tough tool is designed to transmit torque in either direction when placed in the washover string.

Rotary shoes: Rotary shoes are manufactured from specially heat treated alloy to provide the ultimate in thoughness and durability . they are used to cut a clearance between the fish and the wall of the well bore

Model	O.D	I.D	Wall thickness	Min hole size	Max mill size	Max tensile load (KN)	Connection Field torque N.m	Seal pressure (Mpa)
Model	mm					Max tensile load (KN)	Connection Field torque N.m	Seal pressure (Mpa)
TXG114.3-8.56	114.3	97.18	8.56	120.65	80.90	390	9490	20
TXG127-9.19	127.0	108.62	9.19	146.05	101.6	440	12202	20
TXG139.7-9.17	139.7	121.36	9.17	152.4	117.48	500	14914	20
TXG146.05-7.92	146.05	130.21	7.92	161.93	127.00	500	14914	20
TXG146.05-9.00	146.05	128.05	9.00	161.93	120.65	560	16269	20
TXG168.28-8.94	168.28	150.39	8.94	187.33	142.88	600	21693	15
TXG177.8-9.19	117.80	159.42	9.19	200.03	152.40	640	24404	15
TXG193.68-9.53	193.68	174.63	9.53	212.73	168.28	700	31183	15
TXG193.68-10.92	193.68	171.83	10.92	212.73	165.10	810	36607	15
TXG193.68-12.7	193.68	168.28	12.7	212.73	161.93	1060	43386	15
TXG203.2-9.53	203.2	184.15	9.53	215.9	177.00	820	32539	15
TXG206.38-9.4	206.38	187.58	9.40	215.90	177.80	830	32539	15
TXG219.07-11.43	219.07	196.21	11.43	244.48	187.33	1100	47453	15
TXG219.07-12.7	219.07	193.67	12.70	244.48	184.15	1220	54232	15
TXG228.6-10.8	228.6	207.01	10.8	250.83	200.03	1260	47453	15
TXG244.48-11.99	244.48	220.50	11.99	266.70	212.73	1460	67791	15
TXG244.48-13.84	244.48	216.80	13.84	266.70	206.37	1560	81349	15
TXG273.05-11.43	273.05	250.19	11.43	290.45	238.13	1620	81349	15
TXG273.05-12.57	273.05	247.91	12.57	298.45	234.95	1640	88128	15
TXG298.44-12.42	298.44	273.60	12.42	323.85	263.5	1800	108465	10
TXG339.72-13.06	339.72	313.60	13.06	365.13	301.62	2020	149140	10
TXG406.4-16.66	406.40	373.08	16.66	444.50	355.60	2500	254894	7.0
